You can find the address using the output of my program.įor example, if you press the key on your MS2 for the
If this succeeds, and you are able to control the MFX Loko with the MS2, then Now press the "STOP" Button to put current on the track, and the MS2 will beįinding the new Loko, and give it a new address. "STOP" Button is lighting red, and place your "new" MFX Loko on the track. Now you can see all data communications of the CAN-Bus on your screen.Ĭonnect a MS2 if it is not already present, and make sure the Of course you'll have to adjust the IP and Broadcast address You can manually start my program on the Pi with following command: You can retrieve the address of a MFX Loko.Īfter you have completely setup your Pi using my instructions, Using a Märklin Mobile Station 2 and my program for the Pi: PiCanS88, Presenting two ways to find the right address. Getting the address of a MFX Loko can be tricky. The blue connections can only be wired using isolated wires. Its temperature, and if it gets hot, cut the power supply imediatly.
So if youĬonnect this example for the first time, hold your finger on the chip to check Switched, the Chip MCP2551 gets very hot and can get destroyed. Module has to be connected to this example upside-down as you can see in belowĪttention: If the connections CAN High and CAN Low are Pins is opposite, because I couldn't get a real S88-connector. In above mounting instruction, the order of the S88 feedback Using above tams S88-N Adapters can be dangerous, because of reverseįor proper usage please read this part, and if you stillĪll following mounting instructions are based on circuit The S88 ports access must be freed manualy by rasping the case.
Rocrail sensor set manual#
Note: Manual action is required to use thisĬase.
Rocrail sensor set how to#
Is now also added which can be "jumpered" if needed.Ī guide how to solder the empty PCB with the new V2 circuit diagram can be found In addition I am using for the S88 feedback as voltageĭividers the new resistor values 1,8k and 3,3k, which are giving a betterĪn optional Terminating-Resistor for the CAN Bus with 120 Ohm This new version is using the new MCP2562 instead of the old MCP2551.Īdvantage is, this new chip can use 3.3V as reference, and doesn't need voltageĭividers, and it's said to be more stable. You can order these components at this German supplier:īus access including S88 Feedback channel Version 2:
